P10mm SMD5050 Outdoor Rental LED Display
| Catalogue de Produit | Outdoor Rental LED Display |
|---|---|
| Album | Agrandir |
| Modèle | OR-P10MM |
| Resolution | 10000dots/sqm |
| Brightness | >5500CD/sqm |
| Referesh rate | >1200HZ |
| Port | FOB SHENZHEN |
| modalité de paiement | L/C, T/T, Western Union |
| Heure à jour | 2019-12-06 |
Introduction
P10mm SMD5050 Outdoor Rental LED display is highResolution LED Displays, and mostly used in outdoor Event etc, it is importantof advertising during the events time and the cost of the HD video advertisingis decreasing greatly with the improved quality and stable performance.
Advantages of P10mm SMD5050 outdoor Rental led display:
1. Supports signal flowrandomly, satisfies different array and putting in order to create differentimage effects.
2. Equips professionalvideo processor, which supports signal formats like AV, DP, VGA, DVI, YPBPR,HDMI, SDI etc.
3. Supports brightness adjustment and white balance custom adjustment with 256levels, which enables mix usage of different batches of display.
4. Good effect of water proof, with IP65 ingress protection, applied foroutdoor rental use.
P10mm SMD5050 Outdoor Rental LED display Comparedwith traditional outdoor fixed advertising LED Display Screen, there are some differentissues:
1. Lock button
2. Hanging cabinet’s inner structure
3. Hanging beam
4. Bottom Bracket
5. Flight case
for the rental use LED screen: flight case, luck button & hanging structureis always necessary since the screen needs to move from one site to anothervery frequently and only use several days for each event.
If you need other LED Displays Products, Please do not hesitate tocontact with us at sales@porstarled.net. Or view more products at www.pstled.com or www.porstarled.net.
TechnicalSpecification (P10mm SMD5050 Outdoor Rental LED Display):
Pixel configuration | SMD5050 1R1G1B | |
LEDs configuration | Red: wave length: 625~630nm;1100-1300mcd | |
Pixel pitch(mm) | 10 | |
Pixel density | 10000 | |
Calibrated brightness | 5500 nits(adjustable) | |
Calibrated brightness proportion ratio | R: G: B = 30%:60%:10% | |
Color temperature | 3,500°---9,500° K(adjustable) | |
Contrast ratio | 4,500:1 | |
Brightness adjustment(dimming) | 100 grade auto/manual-adjustment | |
View angle(degree)(50% brightness) | Horizontal: 120° (60° off center); Vertical: 70° (+25°/-45° off center) | |
Readability viewing angle | Horizontal: 150° (75° off center); Vertical: 90° (+35°/-55° off center) | |
Color capability | 4.4 trillion | |
Refresh rate(Hz) | >1200 Hz | |
Frame frequency(Hz) | >60 Hz | |
Interface port | DVI interface(DVI connector) | |
Input signal | VGA, Video, AVI, MOV, MPG, DAT, VOB etc. | |
Protection grade | IP65 front side/IP54 backside | |
LED Drive | Constant-current drive | |
Lifetime(hours)(50% brightness) | 100,000 hours | |
Signal transmission direction | Horizontal | |
Operating temperature(Celsius degree) | -30-65' | |
Storage temperature(Celsius degree) | -35-70' | |
Operation humidity(RH) | 0-95% | |
Operation humidity(RH) | 0-99% | |
Servicing | Front and back serving optional | |
Control mode | Synchronous & asynchronous available | |
Communication options | Wire Ethernet, Fiber Ethernet,RF wireless,GPRS | |
Power | 120/240 V AC single phase(50-60Hz) | |
Maximum Power consumption(W/SQM) | 750 | |
Average power consumption(W/SQM) | 300 | |
Screen operation mode(scan/static) | 1/4 | |
Module configuration(Pixels quantities of the module) | Length | 16 |
Height | 16 | |
Module dimensions(mm) | Length | 128 |
Height | 128 | |
Cabinet configuration | Length | 8 |
Height | 6 | |
Cabinet dimensions(mm) | Length | 1024 |
Height | 768 | |
Width | 150 | |
Screen configuration | Length | 4 |
Height | 3 | |
Screen dimensions(m) | Length | 4.09600 |
Height | 2.30400 | |
Screen Size | SQM | 9.44 |
Recommend Optimal Viewing Distance: Minimum & Maximum | Min | 6 |
Max | 136 | |
Resolution ratio(dots/pixels) | Length | 512 |
Height | 288 | |
Aspect Ratio(L:H) | 1.33333 | |
Packaging configuration | 2 standard cabinets in a packing case(1 cabinet in 1 packing case when the unit cabinet is more than 1.5SQM) | |
Packing material | Wooden case/carton/flight case(optional) | |
Packing quantities | 5 | |
Packing volume(CBM) | 4 | |
Packing Dimensions(mm) | Length | 1150 |
Height | 860 | |
Width | 520 | |
Packing weight(KG) | net | 829 |
gross | 1120 | |
LED Display Locks&Hanging Structure:
